Engine Room Harness (Cont'd)
R.H. DRIVE MODEL
NOTE
Mirror of EL-94 for R.H.D. cars: identical connector inventory (E1–E59) but layout flipped. Use together with the connector legend on EL-99 (Cont'd).
Component LocationFig. fig1
R.H.D. engine-room harness connector locations.
1Body ground (rad support / strut tower / battery tray)(Three insets, upper-left edge)
2Battery + battery cable cluster(Lower bay (mirrored))
3Relay box / fusible-link block(Centre bay)
4Headlamp connectors(Front L/R)
5Strut-tower harness pass-through(Strut towers (mirrored))
