HARNESS LAYOUT — Engine Room Harness

EL-94wiring diagram

L.H. Drive Model only — this page depicts the engine room harness layout for left-hand drive vehicles.

Engine Room Harness

Component LocationFig. fig1

Engine room harness connector locations — L.H. Drive Model

Engine room harness layout diagram for L.H. Drive Model showing connector locations E1 through E51 in the engine bay

1E1(center-left engine bay area)

2E2(center-left engine bay area)

3E3(center-left engine bay area)

4E4(center-left engine bay area)

5E5(lower-left engine bay area)

6E6(lower-left engine bay area)

7E7(lower-left engine bay area)

8E8(lower-center engine bay area)

9E9(lower-center engine bay area)

10E10(lower-center engine bay area)

11E11(left-center engine bay area)

12E12(left-center engine bay area)

13E13(left-center engine bay area)

14E14(left-center engine bay area)

15E15(center engine bay area)

16E16(center engine bay area)

17E17(center engine bay area)

18E18(center engine bay area)

19E19(center engine bay area)

20E20(center engine bay area)

21E21(center-left engine bay area)

22E22(right-lower engine bay area)

23E23(right-lower engine bay area)

24E24(right-lower engine bay area)

25E25(lower-center engine bay area)

26E26(lower-center engine bay area)

27E27(lower-center engine bay area)

28E28(lower-center engine bay area)

29E29(lower-center engine bay area)

30E30(right-center lower engine bay area)

31E31(right-center lower engine bay area)

32E32(right-center lower engine bay area)

33E33(right-center engine bay area)

34E34(right-center engine bay area)

35E35(right-center engine bay area)

36E36(right engine bay area)

37E37(far right engine bay area)

38E38(right engine bay area)

39E39(right engine bay area)

40E40(center-right engine bay area)

41E41(far right upper engine bay area)

42E42(far right upper engine bay area)

43E43(far right upper engine bay area)

44E44(center-upper engine bay area)

45E45(upper-center engine bay area)

46E46(upper-center engine bay area)

47E47(upper-center engine bay area)

48E48(upper-center engine bay area)

49E49(upper-center engine bay area)

50E50(upper engine bay area)

51E51(upper-right engine bay area)

Component LocationFig. fig2

Body ground location — connector E41

Inset photo showing body ground location with connector E41 labeled

1E41(body ground point, left side)

2Body ground(label on left side of inset photo)

Component LocationFig. fig3

Body ground location — connector E21

Inset photo showing body ground location with connector E21 labeled

1E21(body ground point, center area)

2Body ground(label on left side of inset photo)

Component LocationFig. fig4

Body ground location — connectors E23 and E24

Inset photo showing body ground location with connectors E23 and E24 labeled

1E23(body ground point, right side)

2E24(body ground point, right side)

3Body ground(label on left side of inset photo)
