ENGINE REMOVAL
EM-31parts diagramParts DiagramFig. fig1
| Specification | Value |
|---|---|
| Fastener torque (mount bracket upper)Engine mount bracket upper bolts (left side upper) | ≈216 - 275N·m |
| Fastener torque (mount bracket)Engine mount bracket bolts (multiple locations) | ≈422 - 539N·m |
| Fastener torque (mount bracket upper right)Right side upper bracket | ≈422 - 539N·m |
| Fastener torque (engine mount to bracket)Right side engine mount to bracket | ≈216 - 255N·m |
| Fastener torque (engine mount insulator right)Right side engine mount insulator bolts | ≈216 - 275N·m |
| Fastener torque (engine mount insulator right lower)Right side engine mount insulator lower | ≈422 - 539N·m |
| Fastener torque (left side engine hanger bracket)Left side engine hanger bracket bolt | ≈177 - 265N·m |
| Fastener torque (transmission mount bracket small bolts)Transmission/gearbox mount bracket small bolts | ≈157 - 206N·m |
| Fastener torque (transmission mount bracket large bolts)Transmission/gearbox mount bracket large bolts | ≈294 - 392N·m |
| Fastener torque (rear mount bracket small)Rear mount bracket small bolts | ≈157 - 206N·m |
| Fastener torque (rear mount bracket lower)Rear mount bracket lower bolts | ≈422 - 539N·m |
| Fastener torque (rear mount insulator lower)Rear mount insulator lower bolts | ≈422 - 539N·m |
Fastener torque (mount bracket upper)Engine mount bracket upper bolts (left side upper)
216 - 275N·m
Fastener torque (mount bracket)Engine mount bracket bolts (multiple locations)
422 - 539N·m
Fastener torque (mount bracket upper right)Right side upper bracket
422 - 539N·m
Fastener torque (engine mount to bracket)Right side engine mount to bracket
216 - 255N·m
Fastener torque (engine mount insulator right)Right side engine mount insulator bolts
216 - 275N·m
Fastener torque (engine mount insulator right lower)Right side engine mount insulator lower
422 - 539N·m
Fastener torque (left side engine hanger bracket)Left side engine hanger bracket bolt
177 - 265N·m
Fastener torque (transmission mount bracket small bolts)Transmission/gearbox mount bracket small bolts
157 - 206N·m
Fastener torque (transmission mount bracket large bolts)Transmission/gearbox mount bracket large bolts
294 - 392N·m
Fastener torque (rear mount bracket small)Rear mount bracket small bolts
157 - 206N·m
Fastener torque (rear mount bracket lower)Rear mount bracket lower bolts
422 - 539N·m
Fastener torque (rear mount insulator lower)Rear mount insulator lower bolts
422 - 539N·m
NOTE
Torque symbol key: Square symbol = N·m (kg·m, ft·lb)
